- Place of Origin: China
- Brand Name: CRYSTAL
- Model Number: AWR2840
ITEMS | AWR2840 |
Max. swig over bed (mm)(inch) | Φ720(28’) |
Max. Size of alloy wheel (inch) | 26’ |
Max. swig over cross slide (mm) | Φ540 |
Cross slide travel (mm) | 350 |
Width of the rail (mm) | 330 |
Length of the rail (mm) | 1320 |
Size of the three-jaw chuck (inch) | 12’ |
Range of spindle speed (RPM) | 50~2000 |
Spindle speed control | Automatic |
Spindle bore (mm) | Φ60 |
Taper of spindle bore | MT6 |
Taper of spindle nose | A2-6 |
Max. size of tool post | 25×25mm |
Stations of tool carrier | 4 position |
Min. setting unit of motor | (Z) long 0.001mm, (X) cross 0.001mm |
Moving speed of post | (Z) long 8m/min, (X) cross 6m/min |
Motor power | 7.5KW |
Machine base | Whole cast iron base |
Machine size(L×W×H) (mm³) | 2300×1750×1950 |
Net weight | 2600kg |
