- Size: 10CBM
- Place of Origin: China
- Brand Name: CRYSTAL
- Model Number: CK6150A
- Weight: 3000.000 kg
Economic configuration
1. CNC Controller :GSK928TD-L
2. Automatic electronic pump lubrication
3. Manual 3-jaw chuck,manual tailstock
4. 4-position electrical tool carrier
5. Single spindle, stepless speed regulation
Optional configurations:
1. Pneumatic chuck or Hydraulic chuck
2. Pneumatic tailstock or Hydraulic tailstock
3. Spring fastener
4. CNC controller: GSK, FANUC Siemens or KND
5. Tool carrier: 4/6/8 -Station tool carrier
- Size: 10CBM
- Place of Origin: China
- Brand Name: CRYSTAL
- Model Number: CK6150A
- Weight: 3000.000 kg
Technical parameters
Items | Specifications |
CK6150A | |
Max. swim over bed | Φ500mm |
Max.swim over carriage | Φ280mm |
Max.length of work piece | 750mm /1000/1250 mm |
Width of the bed | 400mm |
Size of 3-jaw chuck | Φ250mm |
Range of spindle speed | 150-2000rpm |
Spindle bore | Φ82mm |
Taper of spindle bore | Type of spindle head D-8 |
stations of tool carrier | 4-position electrical tool turret or 6/8 |
Max.size of tool post | 25×25mm |
Min.setting unit of motor | (Z) Long 0.001mm (X) Cross 0.001mm |
Moving speed of post | (Z) Long 8 m/min (X) Cross 4 m/min |
Taper of tailstock quill | MT5 |
Max. range of tailstock quill | 150mm |
Motor power | 7.5KW |
Packing size (mm) | 2570/2970 ×1400 ×1650mm
|
Net weight | 3200/3500kg |
Other configuration
CK6150A
| |
Brands of standard configuration of CNC | GSK928TD-L System |
Protective cover and door | metal plate cover, double protective door |
Position of CNC system | On the right, right-left move or customized on the left |
lighting system | standard T8 fluorescent lamp |
Cooling system | water cooling |
Lubrication system | automatic lubrication controlled by microcomputer |
Brands of motor-driven tool carrier | Hongda and Sanhe |
Type of cabinet base | separated type cast iron bed |
